Waveform Control
Variable Dot Technology
Mimaki Advanced Pass System
Mimaki Bulk Ink System
Uninterrupted Ink Supply System
Mimaki Fine Diffusion
| Printhead | Dual On-demand piezo printheads in a staggered configuration |
| Print resolution | Y:300,600 dpi | X:600,1200 dpi |
| Print speed (4 color mode) | up to 969 sqft/hr (90 sqm/hr) |
| Maximum Print Area | 127.6 in (3,240 mm) |
| Maximum media width | 127.9 in (3,250 mm) |
| Maximum Media Thickness | up to 0.04 in (1 mm) |
| Maximum Media Weight | Roll weight: 220 lbs. (100 kg) |
| Ink Type | Sublimation Ink: Sb411 (Bl, M, Y, K) and Sb420 (Bl, M, Y, K) |
| Interface | Ethernet 1000 BASE-T / (USB2.0 Hi-speed) |
| Power Supply | Single-phase AC100-120 / 200-240V±10%, 50/60Hz±1Hz |
| Power Consumption | Max AC200-240V / 2400W |
| Operational Environment | Temperature: 20–30 °C (68–86 °F) |
| Dimensions (W × D × H) | 5,410 x 1,075 x 1,440 cm (213 x 42.32 x 56.69 in) |
| Weight | 529.1 lbs (240 kg) |
| Certifications | VCCI Class A, FCC Class A, IEC 62368-1 ETL compliance, CE marking (EMC Directive, Low Voltage Directive, Machinery Directive, RoHS Directive), CB certified, REACH, EnergyStar, RCM marking, KC certified, UKCA marking |
| Dye Sublimation Ink (SB411, SB420) | Blue | Magenta | Yellow | Black | ||
|---|---|---|---|---|---|---|
| 2L Ink Pack | S411-BLT-2L | SB411-MT-2L | SB411-YT-2L | SB411-KT-2L |
| Dye Sublimation Ink (SB411, SB420) | |
|---|---|
| 2L Ink Pack |
|
