List Price (USD):
Valid in USA and Canada only
JFX200-1213 EX: TBA

Big impact, small footprint

The Mimaki JFX200-1213 EX medium-format UV-LED flatbed printer is engineered for small to medium volume production, offering wide-format printing capabilities in a compact footprint. It meets the needs of print service providers and in-house print shops with limited space, delivering high-quality outputs across various applications, including textured surfaces, ADA-compliant signage, and jig workflows.
  • Compact medium format design enables businesses to expand their production capabilities without requiring the space of a traditional wide-format printer.
  • High versatility inks for printing to a wide range of rigid and flexible surfaces.
  • Capable of producing 2.5D textures and ADA signage.
  • Produce medium production volumes, such as printing multiple 18”x 24” signs simultaneously, or jig printing.
  • IoT ready, Remote monitoring available through Mimaki PICT software for performance and production monitoring and event notification.
  • Uses Greenguard Gold certified inks.

Our Core Technologies


Waveform Control


Variable Dot Technology


Mimaki Advanced Pass System


Nozzle Recovery System


Mimaki Bulk Ink System


Mimaki Circulation Technology


Mimaki Fine Diffusion

Applications

img img img img img img img img img img img img img

Specifications

Printhead

Three staggered on-demand piezo heads

Print resolution

300, 450, 600, 900, 1,200dpi

Print Speed (4 Color Mode)

up to 269 SqFt/Hr (25 m2/h)

Maximum Print Area

50.0 in x 51.2 in (1270 mm x 1300 mm)

Maximum media area

52 in x 54 in (1320 mm x 1370 mm)

Maximum Media Thickness

up to 1.97″ (50 mm)

Maximum Media Weight

110.3 lbs. (50.0 kg)

Ink Type

Rigid: LH-100 ink; C, M, Y, K, Lc, Lm, W, Cl

Flexible:

LUS-150 ink; C, M, Y, K, Lc, Lm, W with LUS-100 Cl

LUS-120 ink; C, M, Y, K, W, Cl

LUS-350 ink; C, M, Y, K, W, Cl

Interface

Ethernet 10,000 BASE-T

Power Supply

Single phase AC200-240±10% 50/60 Hz±1 Hz x 1

Power Consumption

2.88 kVA or less

Operational Environment

Temperature 68° – 86° F (15-30° C)
Humidity: 35–65 % RH (Non condensing)

Dimensions (W × D × H)

125 in W x 96 in D x 49 in H (3175 mm W x 2450 mm D x 1250 mm H)

Weight

1124 lbs. (510 kg)

Certifications

VCCI Class A, CE Mark, CB Report, US safety standard UL (UL62368-1),RoHS Directive,

FCC Class A, Machinery Directive, RCM

Inks

JFX200-1213 EXCyanMagentaYellowBlackLight CyanLight MagentaWhiteClearPrimer
UV Curable Ink (LH-100) 1L BottleLH100-C-BALH100-M-BALH100-Y-BALH100-K-BALH100-W-BALH100-CL-BA
UV Curable Ink (LUS-120) 1L BottleLUS12-C-BALUS12-M-BALUS12-Y-BALUS12-K-BALUS12-W-BALUS12-CL-BA
UV Curable Ink (LUS-150) 1L BottleLUS15-C-BALUS15-M-BALUS15-Y-BALUS15-K-BALUS15-LC-BALUS15-LM-BALUS15-W-BA(Use LH-100)
UV Curable Ink (LUS-350) 1L BottleLUS35-C-BALUS35-M-BALUS35-Y-BALUS35-K-BALUS35-W-BALUS35-CL-BA
UV Primer (PR-200) 1L BottlePR-200-Z-BA

Inks

JFX200-1213 EX
UV Curable Ink (LH-100) 1L Bottle
Cyan:
LH100-C-BA
Magenta:
LH100-M-BA
Yellow:
LH100-Y-BA
Black:
LH100-K-BA
Light Cyan:
_ _
Light Magenta:
_ _
White:
LH100-W-BA
Clear:
LH100-CL-BA
Primer:
_ _
UV Curable Ink (LUS-120) 1L Bottle
Cyan:
LUS12-C-BA
Magenta:
LUS12-M-BA
Yellow:
LUS12-Y-BA
Black:
LUS12-K-BA
Light Cyan:
_ _
Light Magenta:
_ _
White:
LUS12-W-BA
Clear:
LUS12-CL-BA
Primer:
_ _
UV Curable Ink (LUS-150) 1L Bottle
Cyan:
LUS15-C-BA
Magenta:
LUS15-M-BA
Yellow:
LUS15-Y-BA
Black:
LUS15-K-BA
Light Cyan:
LUS15-LC-BA
Light Magenta:
LUS15-LM-BA
White:
LUS15-W-BA
Clear:
(Use LH-100)
Primer:
_ _
UV Curable Ink (LUS-350) 1L Bottle
Cyan:
LUS35-C-BA
Magenta:
LUS35-M-BA
Yellow:
LUS35-Y-BA
Black:
LUS35-K-BA
Light Cyan:
_ _
Light Magenta:
_ _
White:
LUS35-W-BA
Clear:
LUS35-CL-BA
Primer:
_ _
UV Primer (PR-200) 1L Bottle
Cyan:
_ _
Magenta:
_ _
Yellow:
_ _
Black:
_ _
Light Cyan:
_ _
Light Magenta:
_ _
White:
_ _
Clear:
_ _
Primer:
PR-200-Z-BA
